bolster plate

3D contact analysis of forging die and bolster plate on hydraulic press

液压机模具与支承部件的三维接触分析

Parameter Optimization Design of Bolster Plate of Multi-link Press based on AlGOR

基于ALGOR的多连杆压力机工作台台板厚度参数优化设计

Finite element analysis on bolster plate of hydraulic press for divergent transimission load Harbin Institute of Technology

水压机垫板对载荷发散传递的有限元分析

The result shows some cracks appearing on vertical weld connecting web plate of body bolster and draft sill as well as the part between web plate of body bolster and top cover plate.

试验结果表明，无中梁罐车存在枕梁腹板与牵引梁立焊缝裂纹及枕梁腹板与枕梁上盖板之间的裂纹。

In this paper, the load which the bolster plates transmit in hydraulic press are analyzed by finite element method with plane stress elements. The results of calculation show the effect of bolster plate height and load area on transmission of load.

采用平面应力单元，对水压机加载时垫板对载荷的传递进行了有限元分析，得到了垫板高度以及加载区域对力的传递的影响规律。
